The ThinkPad 1TB 5400RPM 6Gb/s 2.5" SATA Hard Drive option provides a robust thin design enabling a seamless upgrade from the primary hard drive of supported ThinkPad laptops. This affordable option provides good storage size along with advanced format and SATA data transfer capabilities. For additional storage and backup, install this drive as a second hard drive using the ThinkPad 9.5mm SATA Hard Drive Bay Adapter IV (0B47315).
Products specifications
| HDD capacity | 1 TB |
| HDD speed | 5400 RPM |
| Storage drive buffer size | 16 MB |
| HDD size | 2.5" |
| Interface | Serial ATA III |
| Type | HDD |
| HDD sustained transfer rate | 140 MiB/s |
| Read seek time | 12 ms |
| Write seek time | 13 ms |
| Width | 69.8 mm |
| Height | 7 mm |
| Depth | 100.3 mm |
| Weight | 94 g |
| Compliance certificates | RoHS |
| Certification | CE UL KC TUV BSMI C-Tick CUL |
| Harmonized System (HS) code | 84717050 |
| Quantity per pack | 1 pc(s) |
| Package width | 144 mm |
| Package depth | 177 mm |
| Package weight | 227 g |
| Package height | 53 mm |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Power consumption (typical) | 5 W |
| Operating voltage | 5 V |
