Outstanding Visibility
Beyond Window
High Visibility
Under The Sunlight
With a great brightness of 4,000 nits, XS4J clearly delivers contents and attract public attention, which is the ultimate display for outdoor visibility. QWP enables clear visibility even when the viewer is wearing polarized sunglasses.
High Performance with webOS
Quad Core SoC can execute several tasks at the same time without a separate media player. In addition, webOS 4.1 platform enhances user convenience with intuitive UI and simple app development tools.
Slim Bezel Design
XS4J attracts attention with elegant design, featuring a slim bezel. These displays enhance the visual impact of the played content and the store’s overall atmosphere.
Wide Operating
Temperature Range
XS4J can operate at various temperatures of 0-40°C.
Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
High Energy Efficiency
XS4J is energy efficient, allowing for an efficient total cost management while showing content with 4,000 nits of high brightness.
Easy Content Distribution & SW Update
XS4J features embedded Wi-Fi making it easy to distribute content wirelessly and update Firmware.
Web Monitoring (Control Manager)
This is a web-based monitoring solution, which provides a ease of control for the user. It enables users to have full access anywhere, anytime from their mobile phone & PC as long as they’re connected to a network while having access to both current and past data. It allows users to monitor the unit, make any adjustments and control it remotely in real-time.
Products specifications
| Wall mountable | Yes |
| Display width | 1092.7 mm |
| Display depth | 83.5 mm |
| Display height | 626.4 mm |
| Display weight | 20.8 kg |
| Package weight | 25.3 kg |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Power consumption (typical) | 345 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Heat dissipation | 1177 BTU/h |
| Certification | CB / NRTL FCC Class "A" / CE / KC / VCCI ErP |
| HDMI ports quantity | 2 |
| HDMI version | 1.4 |
| HDMI input ports quantity | 2 |
| DVI port | No |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| Number of speaker outputs | 2 |
| RS-232C | Yes |
| Remote (IR) input | 1 |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 9 mm |
| Bezel width (side) | 6.5 mm |
| Bezel width (top) | 9 mm |
| Analog signal format system | NTSC |
| Ambient light sensor | Yes |
| Operating hours (hours/days) | 24/7 |
| Display diagonal | 124.5 cm (49") |
| Display technology | IPS |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 4000 cd/m² |
| HD type | Full HD |
| Touchscreen | No |
| Response time | 8 ms |
| Contrast ratio (typical) | 1300:1 |
| Contrast ratio (dynamic) | 500000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC, HDMI |
| Built-in speaker(s) | No |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Internal memory | 16 GB |
| Operating system installed | WebOS |
