The Neomounts WL30-350BL14 is a fixed wall mount for flat screens up to 65" with a maximum weight capacity of 40 kg.
The WL30-350BL14 has a depth of 3,9 cm and is suitable for screens that meet VESA hole pattern 50x50 to 400x400 mm. It is possible to lock the individual brackets of the mount using a padlock (not included).
A practical bolt bag is included in the packaging, for quick and easy installation.
Products specifications
| Width | 450 mm |
| Depth | 39 mm |
| Height | 425 mm |
| Weight | 1 kg |
| Warranty period | 5 year(s) |
| Master (outer) case width | 267 mm |
| Master (outer) case length | 210 mm |
| Master (outer) case height | 570 mm |
| Master (outer) case gross weight | 19.9 kg |
| Products per master (outer) case | 15 pc(s) |
| Country of origin | China |
| Master (outer) case net weight | 15 kg |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 630 pc(s) |
| Package width | 63 mm |
| Package depth | 50 mm |
| Package height | 550 mm |
| Package net weight | 1.3 kg |
| Package weight | 1.3 kg |
| Housing material | Steel |
| Product colour | Black |
| Accepts padlock | Yes |
| Cable management | No |
| Maximum weight capacity | 40 kg |
| Minimum screen size | 81.3 cm (32") |
| Number of displays supported | 1 |
| Maximum screen size | 165.1 cm (65") |
| Suitable for TV | Yes |
| Mounting type | Wall |
| Minimum VESA mount | 50 x 50 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 75 x 75,100 x 100,50 x 50,100 x 200,200 x 200,200 x 400,400 x 400,200 x 300,300 x 300,300 x 200,400 x 300,200 x 100,300 x 100,100 x 150,120 x 120,75 x 200,100 x 75,75 x 100,350 x 350,400 x 200,150 x 200,200 x 150 |
| Distance to the wall (max) | 3.9 cm |
