The Neomounts WL30-750BL18P LEVEL is the ultimate solution for securely portrait mounting an interactive or heavy weight display up to 98" with a maximum capacity of 100 kg. This heavy-duty wall mount features a high profile wall plate and is engineered for stability and precision, ensuring your screen is securely mounted even on uneven surfaces. The wall mount is designed to provide the sturdiest and most stable touch screen experience. The brackets of the WL30-750BL18P feature depth adjustable wall supports on the lower brackets for better weight distribution and maximum stability. The mount features individual adjustable brackets (10 mm) for securely adjusting the display height or levelling it.
The LEVEL-750 wall mount has a profile depth of 4,2 cm and is suitable for screens that meet VESA hole pattern 100x100 to 500x800 mm. Its quickly connectable wall plate allows for multiple screen mounting, while a clever kickstand service position provides easy access to cables and connectors, ideal when mounting large displays in portrait. Additionally, the wall plate is designed with specific cut-outs for wall sockets and securing devices and cables. It features various perforated holes for easy tie-wrap cable fixing and provides space for cable storage, ensuring a clean and tidy finishing.
The WL30-750BL18P includes an safe and practical pull & release system, allowing you to quickly attach and detach the display in a safe and secure manner. It is possible to lock the brackets using a padlock (not included) for extra screen security.
For a simple and effective storage, an optionally available, AV-rack can be installed to the left or right side of the mount.
Products specifications
| Width | 550 mm |
| Depth | 42 mm |
| Height | 684 mm |
| Weight | 5.1 kg |
| Master (outer) case width | 951 mm |
| Master (outer) case length | 227 mm |
| Master (outer) case height | 288 mm |
| Master (outer) case gross weight | 21 kg |
| Master (outer) case net weight | 15.3 kg |
| Products per master (outer) case | 3 pc(s) |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 54 pc(s) |
| Package width | 933 mm |
| Package depth | 90 mm |
| Package height | 209 mm |
| Package weight | 6.7 kg |
| Country of origin | China |
| Lockable | Padlock not included |
| Product colour | Black |
| Housing material | Steel |
| Height adjustment | Yes |
| Height adjustment range | 0 - 10 mm |
| Cable management | Yes |
| Type | Fixed |
| Distance to the wall (max) | 4.2 cm |
| Maximum weight capacity | 100 kg |
| Minimum screen size | 127 cm (50") |
| Number of displays supported | 1 |
| Maximum screen size | 2.49 m (98") |
| Minimum VESA mount | 100 x 100 mm |
| Maximum VESA mount | 500 x 800 mm |
| Panel mounting interface | 100 x 100,100 x 200,200 x 200,200 x 400,400 x 400,400 x 600,200 x 300,300 x 300,440 x 400,500 x 400,300 x 200,400 x 300,400 x 500,200 x 100,300 x 100,460 x 640,100 x 150,120 x 120,350 x 350,400 x 200,500 x 500,150 x 200,200 x 150 |
| Mounting type | Wall |
