The Zyxel NWA1123ACv3 802.11ac Wave 2 Dual-Radio PoE Access Point supports a combined data rate of up to 1.2Gbps. With Zyxel’s innovative design and commitment to “RF First” for high performance and reliable connections through design, the NWA1123ACv3 delivers increased coverage and improved connection speeds for every client.
The NWA1123ACv3 supports NebulaFlex, giving you the ability to easily switch between standalone and our license free Nebula cloud management, anytime, with a few simple clicks.
Best interior WiFi performance in style
Struggling between performance and environment cohesion when deploying business wireless APs is in the past. The stylish exterior of NWA1123ACv3 is suitable for any interior that not only outperforms but also blends into the interior better as well as preventing the equipment theft.
Optimize for what you need
To create a thoroughly enhanced WiFi experience, NWA1123ACv3 made a big move on MU-MIMO and RF First design via fine-tuned software and innovative hardware.
Featuring with DCS and load-balance, NWA1123ACv3 delivers smooth and superior WiFi experience in workplaces.
WPA3 WiFi security for Safer Networks
Supporting the latest WPA3 standard, the NWA1123ACv3 is designed to bring stronger encryption and authentication to protect your wireless network.
Manage it your way!
As it comes with the support of NebulaFlex, Zyxel’s scalable, cloud-based management system, the NWA1123ACv3 can be managed via NCC (Nebula Control Center), or simply operates alone (controller-less). You can choose the way that is best suited to your needs.
Products specifications
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 866 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 866 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n, IEEE 802.1x |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| VLAN support | Yes |
| Width | 140 mm |
| Depth | 141 mm |
| Height | 37.5 mm |
| Weight | 249 g |
| Harmonized System (HS) code | 85176990 |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 0.3 A |
| Output voltage | +12 V |
| Output current | 1 A |
| Power supply | 11 W |
| Ethernet LAN (RJ-45) ports | 1 |
| Placement | Ceiling |
| Product colour | White |
| LED indicators | Yes |
| Security algorithms | 802.1x RADIUS, EAP, WEP, WPA, WPA2-Enterprise, WPA2-PSK, WPA3 |
| MAC address filtering | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Antenna type | Internal |
