Customers and staff alike will appreciate the PLQ-22/22M's unobtrusive noise levels, which are as low as 51dBA. It’s efficient, too – the print speed enhancer enables fast printing of bit image data under Windows® environments to help cut queues.
The 'M' version has a high-accuracy MICR/MSRW head for smooth, trouble-free handling of cheques and passbooks.
Low total cost of ownership
Delivering substantial cost and energy savings, the PLQ-22/22M is qualified by ENERGY STAR®, and has a very low standby power consumption of 4.5W. Further reducing TCO, it can print around 10 million characters in draft mode between ribbon changes.
Flexible
The PLQ-22/22M offers excellent passbook handling and data processing flexibility, thanks to its 128kb memory and capacity for passbooks up to 2.6mm thick.
Easy installation
Simple to install, the PLQ-22/22M features a choice of emulations plus parallel, serial and USB interfaces as standard for an easy fit into most IT environments.
Products specifications
| Product colour | Grey |
| Buffer size | 128 KB |
| Sound pressure level (printing) | 54 dB |
| Page description languages | Epson ESC/P2, PPDS |
| Country of origin | Indonesia |
| Width | 384 mm |
| Depth | 280 mm |
| Height | 203 mm |
| Weight | 8.2 kg |
| Media types supported | Passbooks, cheque |
| Connectivity technology | Wired |
| Print technology | Dot matrix |
| Box contents | Power cable, Ribbon, Setup guide, User manual (CD), Warranty document |
| Needles | 24 |
| Products per pallet | 32 pc(s) |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet gross height | 2.47 m |
| Products per pallet layer | 4 pc(s) |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet (UK) | 48 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet width (UK) | 100 cm |
| Pallet height (UK) | 2.47 m |
| Harmonized System (HS) code | 84433210 |
| Quantity per pack | 1 pc(s) |
| Package width | 260 mm |
| Package depth | 450 mm |
| Package height | 365 mm |
| Package weight | 9.48 g |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Power consumption (typical) | 65 W |
| AC input voltage | 220 - 240 V |
| Standard interfaces | Parallel, RS-232, USB 2.0 |
| Windows operating systems supported | Windows 7, Windows 7 Professional, Windows 8, Windows Vista, Windows XP, Windows XP Home x64 |
| Maximum resolution | 360 x 360 DPI |
| Maximum printing width (columns) | 94 |
| Maximum print speed | 480 cps |
| Maximum print speed (draft) | 360 cps |
| Maximum print speed (LQ) | 120 cps |
| Character pitch | 10 cpi |
| Maximum number of copies | 7 copies |
| Maximum print size | A4 / Letter (216 x 297 mm) |
| Cut sheet width range | 65 - 245 mm |
| Cut sheet length range | 67 - 297 mm |
| Print head | 24-pin |
| Print direction | Bidirectional |
| Print head life | 400 million characters |
| Ribbon life (black, draft) | 10 million characters |
| Ribbon life (black, LQ) | 5 million characters |
| Mean time between failures (MTBF) | 10000 h |
