Low total cost of ownership
Delivering substantial cost and energy savings, the PLQ-30M has a very low standby power consumption of 4.5W. Further reducing TCO, it can print around 10 million characters in draft mode between ribbon changes.
Flexible
It offers excellent passbook handling and data processing flexibility, thanks to its 128kb memory and capacity for passbooks up to 2.6mm thick.
Easy installation
Simple to install, the PLQ-30M features a choice of emulations plus parallel, serial and USB interfaces as standard for an easy fit into most IT environments.
Ultra-high-speed draft mode
High speed print speeds of 585 cps.
Products specifications
| Product colour | Grey |
| Buffer size | 128 KB |
| Sound pressure level (printing) | 55 dB |
| Page description languages | ESC P, PPDS |
| Country of origin | Indonesia |
| Width | 384 mm |
| Depth | 280 mm |
| Height | 203 mm |
| Weight | 8.9 kg |
| Box contents | Power cable, Ribbon, Setup guide, User manual (CD), Warranty document |
| Needles | 24 (2 x 12) |
| Products per pallet | 32 pc(s) |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet gross height | 3.71 m |
| Products per pallet layer | 4 pc(s) |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet (UK) | 48 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet width (UK) | 100 cm |
| Pallet height (UK) | 3.71 m |
| Harmonized System (HS) code | 84433210 |
| Quantity per pack | 1 pc(s) |
| Package width | 253 mm |
| Package depth | 450 mm |
| Package height | 365 mm |
| Package weight | 10.44 g |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Power consumption (typical) | 64 W |
| Power consumption (standby) | 4.5 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Standard interfaces | RS-232, USB 2.0 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP, Yes |
| Maximum printing width (columns) | 94 |
| Maximum print speed | 585 cps |
| Maximum print speed (draft) | 390 cps |
| Maximum print speed (LQ) | 130 cps |
| Character pitch | 10 cpi |
| Maximum number of copies | 7 copies |
| Built-in barcodes | CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, UPC-A, UPC-E |
| Character sets | PC864, ISO 8859-15, PC437, PC850, PC858, PC860 |
| Paper tray media types | Envelopes |
| Single sheet thickness range | 0.065 - 0.19 mm |
| Print head | 24-pin |
| Print direction | Bidirectional |
| Mean time between failures (MTBF) | 12000 h |
