| Width | 445 mm |
| Depth | 720 mm |
| Height | 87 mm |
| Harmonized System (HS) code | 84714100 |
| Operating temperature (T-T) | 5 - 45 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage relative humidity (H-H) | 8 - 90% |
| Operating altitude | 0 - 3050 m |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1100 W |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 1 |
| Power supply input frequency | 50 - 60 Hz |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| VGA (D-Sub) ports quantity | 1 |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Chassis type | Rack (2U) |
| Product colour | Black |
| Rack mounting | Yes |
| Redundant fans support | Yes |
| Rack rails | Yes |
| Performance management | XClarity Enterprise |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Sustainability certificates | ENERGY STAR |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® Gold |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor model | 5218 |
| Processor frequency | 2.3 GHz |
| Processor boost frequency | 3.9 GHz |
| Processor cores | 16 |
| Processor cache | 22 MB |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 125 W |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Processor codename | Cascade Lake |
| Tcase | 87 °C |
| Maximum internal memory supported by processor | 1.02 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2667 MHz |
| Execute Disable Bit | Yes |
| Maximum number of PCI Express lanes | 48 |
| Processor package size | 76.0 x 56.5 mm |
| Supported instruction sets | AVX-512 |
| Scalability | 4S |
| Embedded options available | No |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 24 |
| ECC | Yes |
| Memory clock speed | 2666 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Maximum internal memory | 3 TB |
| Maximum storage capacity | 396 TB |
| Total storage capacity | 0 GB |
| Number of HDDs supported | 24 |
| Supported HDD sizes | 2.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Optical drive type | No |
| Supported storage drive interfaces | SAS, Serial ATA III |
| Card reader integrated | No |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Not available |
| PCI Express x8 slots | 2 |
| PCI Express slots version | 3.0 |
| Compatible operating systems | Microsoft Windows Server 2012 R2, 2016, and 2019; Red Hat Enterprise Linux 6 (x64), 7, and 8; SUSELinux Enterprise Server 11 (x64), 12, and 15; VMware vSphere (ESXi) 6.0, 6.5, and 6.7 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 192444 |
