Sharp ePaper Displays - groundbreaking advance in energy-efficient signage technology
A groundbreaking advance in energy-efficient signage technology, the ePaper Display consumes a remarkable zero watts when presenting content. Taking only minimal power draw when content changes, innovation in ePaper signage is making a significant step forward toward the carbon-neutral era.
A digital alternative to paper posters, full colour ePaper presents static content that’s always on display, but might need regular updating, such as POS promotions, menu boards and allergen information in retail and hospitality locations, or timetables, check-in, and gate information in transportation settings. Visible in bright environments, with a paper-like appearance that’s easy on the eyes with no reflections nor blue light, ePaper is signposting for sustainability and viewer comfort.
An integrated SoC secures smart and future proof operation, driving content via selected CMS partners, or enjoy the simplest content management using USB, Wifi or Bluetooth.
The ultra-light weight ePaper display can be hung like a picture frame or free standing in any orientation. Capable of being powered by battery with no need for a power cable, it demands little in the way of installation and even less during operation.
Products specifications
| Display width | 306.4 mm |
| Display depth | 20.9 mm |
| Display height | 229.9 mm |
| Display weight | 700 g |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Package width | 365 mm |
| Package depth | 124 mm |
| Package height | 299 mm |
| Package weight | 2 kg |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| DVI port | No |
| USB port | Yes |
| USB ports quantity | 2 |
| USB connector type | USB Type-C |
| Ethernet LAN | No |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | White |
| VESA mounting | Yes |
| Panel mounting interface | 200 x 200 mm |
| Purpose | Universal |
| Display diagonal | 33.8 cm (13.3") |
| Display resolution | 1600 x 1200 pixels |
| HD type | UXGA |
| Touchscreen | No |
| Native aspect ratio | 4:3 |
| Display diagonal (metric) | 33.8 cm |
| Stand included | Yes |
| Power adapter included | Yes |
| Cables included | AC |
| Mounting kit | Yes |
| Built-in speaker(s) | No |
