TP-Link VIGI 16 Channel PoE+ Network Video Recorder 4TB

TP-Link VIGI 16 Channel PoE+ Network Video Recorder 4TB. Video input channels: 16 channels, Maximum resolution: 3840 x 2160 pixels, Number of simultaneously playbacked channels: 16 channels. HDD capacity: 4 TB, Maximum storage capacity: 32000 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at. Product colour: Black. Power consumption (max): 40 W, Power consumption (typical): 6.2 W, Power over Ethernet (PoE) power per port: 30 W
Manufacturer: TP-Link
SKU: VIGI NVR2016H-16MP-4TB
Vendor: Aspects
Security Never Shuts Down
16MP16 Channel PoE+ Network Video Recorder

Every Angle All on One Screen

4K HDMI Video Output & 16MP Decoding Capacity
Sharp image definition up to 8MP (4K) ensures you capture every detail. 8-ch@2MP decoding capacity allows you to enjoy more-channels live view and playback at the same time.

Dedicated 16 PoE+ Ports for Simplified IP Camera Deployment.
Designed to use a single Ethernet cable for both data and power transmission, this NVR offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions.

Reviewing Footage is Faster than Ever

16-Channel Simultaneous Playback*
Replay the feed from up to 16 cameras at the same time, increase replay speed,
and find events in the video schedule to easily review footage.

More Compression. More Savings. More Quality.
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.

No Need to Check Long Compatibility Lists
ONVIF Ensures Compatibility
Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility.

Auto Initialize for Quick Configuration
Just click "Auto Initialize" to set up basic IPC and hard disk parameters, including initialization and recording plans, significantly reducing your configuration time.

Security for Every Hour and Every Day
27/4 Continuous Recording
With the storage capacity of up to 20TB, the NVR supports 24/7 continuous local recording. Customize record schedule or record type to save storage space and quickly search out target footage.

Two-Way Audio
With voice intercom support, scare off any potential thieves or intruders from wherever you are.

Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.

Live Views and Real-Time Alerts
Easily check your business security via 24/7 live views. Get notifications as soon as the cameras detect something abnormal.

Easy & Smart Playback
Quickly review and locate certain video clips by event, vehicle, person, time, and more. This will greatly improve event backtracking efficiency and reduce labor costs.

Easy & Smart Playback
Quickly review and locate certain video clips by event, vehicle, person, time, and more. This will greatly improve event backtracking efficiency and reduce labor costs.

Four-Way Management
Flexibly manage your cameras via the web UI, NVR UI, VIGI app, and VIGI Security Manager for ease and convenience.

One system. Full security.
Run your business with peace of mind.

The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
  • Legal warranty via the seller
  • 30 days to change your mind — free returns
  • Free delivery from €25
€1207.50 incl tax
increase decrease
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Security Never Shuts Down
16MP16 Channel PoE+ Network Video Recorder

Every Angle All on One Screen

4K HDMI Video Output & 16MP Decoding Capacity
Sharp image definition up to 8MP (4K) ensures you capture every detail. 8-ch@2MP decoding capacity allows you to enjoy more-channels live view and playback at the same time.

Dedicated 16 PoE+ Ports for Simplified IP Camera Deployment.
Designed to use a single Ethernet cable for both data and power transmission, this NVR offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions.

Reviewing Footage is Faster than Ever

16-Channel Simultaneous Playback*
Replay the feed from up to 16 cameras at the same time, increase replay speed,
and find events in the video schedule to easily review footage.

More Compression. More Savings. More Quality.
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.

No Need to Check Long Compatibility Lists
ONVIF Ensures Compatibility
Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility.

Auto Initialize for Quick Configuration
Just click "Auto Initialize" to set up basic IPC and hard disk parameters, including initialization and recording plans, significantly reducing your configuration time.

Security for Every Hour and Every Day
27/4 Continuous Recording
With the storage capacity of up to 20TB, the NVR supports 24/7 continuous local recording. Customize record schedule or record type to save storage space and quickly search out target footage.

Two-Way Audio
With voice intercom support, scare off any potential thieves or intruders from wherever you are.

Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.

Live Views and Real-Time Alerts
Easily check your business security via 24/7 live views. Get notifications as soon as the cameras detect something abnormal.

Easy & Smart Playback
Quickly review and locate certain video clips by event, vehicle, person, time, and more. This will greatly improve event backtracking efficiency and reduce labor costs.

Easy & Smart Playback
Quickly review and locate certain video clips by event, vehicle, person, time, and more. This will greatly improve event backtracking efficiency and reduce labor costs.

Four-Way Management
Flexibly manage your cameras via the web UI, NVR UI, VIGI app, and VIGI Security Manager for ease and convenience.

One system. Full security.
Run your business with peace of mind.

The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
Products specifications
Features
Reset buttonYes
Product colourBlack
Weight & dimensions
Width330 mm
Depth285 mm
Height45 mm
Weight2.1 kg
Package weight4.1 kg
Operational conditions
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90%
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)10 - 90%
Power
Power consumption (max)40 W
Power consumption (typical)6.2 W
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget140 W
Technical details
Compliance certificatesBSMI, CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RCM, UKCA, VCCI
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Power over Ethernet (PoE)Yes
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE) ports quantity16
HDMI ports quantity1
VGA (D-Sub) output ports1
USB 2.0 ports quantity2
Audio RCA inputs1
Audio RCA outputs1
eSATA ports quantity1
eSATAYes
DC-in jackYes
Networking standardsIEEE 802.3af, IEEE 802.3at
Performance
Video input channels16 channels
Number of simultaneously playbacked channels16 channels
Video recording modes720p, 1080p, 2160p
Maximum resolution3840 x 2160 pixels
Supported resolutions3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video motion detectionYes
Video loss detectionYes
Multi-screenYes
Audio formats supportedG.711, G.711 μ-law, G.726
Video formats supportedH.264, H.264+, H.265, H.265+
Playback modesFast play, Forward, Frame by Frame, Full screen, Pause, Play, Reverse
Maximum frame rate30 fps
Input bandwidth80 Mbit/s
Output bandwidth60 Mbit/s
Packaging content
Packaging content1x Lock Plate; 1x Wall Plate; 2x Distance Washers; 2x Screws 4.2x16; 2x Vertical Plate incl. Hook; 8x Screws M6x12; 8x Washers 6x19x1
System requirements
Mobile operating systems supportedAndroid, iOS
Browser supportedChrome (57+), Firefox (52+), Edge (91+)
Wireless LAN features
Wi-FiNo
Hard drive
Number of HDDs installed1
HDD capacity4 TB
Number of HDDs supported2
Total installed storage capacity4 TB
Maximum storage capacity32000 TB
HDD interfaceSATA
*
*
*
Products specifications
Features
Reset buttonYes
Product colourBlack
Weight & dimensions
Width330 mm
Depth285 mm
Height45 mm
Weight2.1 kg
Package weight4.1 kg
Operational conditions
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90%
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)10 - 90%
Power
Power consumption (max)40 W
Power consumption (typical)6.2 W
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget140 W
Technical details
Compliance certificatesBSMI, CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RCM, UKCA, VCCI
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Power over Ethernet (PoE)Yes
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE) ports quantity16
HDMI ports quantity1
VGA (D-Sub) output ports1
USB 2.0 ports quantity2
Audio RCA inputs1
Audio RCA outputs1
eSATA ports quantity1
eSATAYes
DC-in jackYes
Networking standardsIEEE 802.3af, IEEE 802.3at
Performance
Video input channels16 channels
Number of simultaneously playbacked channels16 channels
Video recording modes720p, 1080p, 2160p
Maximum resolution3840 x 2160 pixels
Supported resolutions3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video motion detectionYes
Video loss detectionYes
Multi-screenYes
Audio formats supportedG.711, G.711 μ-law, G.726
Video formats supportedH.264, H.264+, H.265, H.265+
Playback modesFast play, Forward, Frame by Frame, Full screen, Pause, Play, Reverse
Maximum frame rate30 fps
Input bandwidth80 Mbit/s
Output bandwidth60 Mbit/s
Packaging content
Packaging content1x Lock Plate; 1x Wall Plate; 2x Distance Washers; 2x Screws 4.2x16; 2x Vertical Plate incl. Hook; 8x Screws M6x12; 8x Washers 6x19x1
System requirements
Mobile operating systems supportedAndroid, iOS
Browser supportedChrome (57+), Firefox (52+), Edge (91+)
Wireless LAN features
Wi-FiNo
Hard drive
Number of HDDs installed1
HDD capacity4 TB
Number of HDDs supported2
Total installed storage capacity4 TB
Maximum storage capacity32000 TB
HDD interfaceSATA
