How many Orbi Satellites do you need?
COVERAGE AREA
Consider square footage beyond your home footprint to maximize performance and ensure coverage for outdoor areas.
HOME SHAPE
L or U-shaped homes may need additional satellites to extend WiFi around corners.
WIRED CONNECTIONS
Orbi satellites give your ultra-fast wired connections where you need them.
CONSTRUCTION MATERIALS
Brick and concrete weaken WiFi signals. Add-on satellites will strengthen WiFi coverage.
COVERAGE AREA
Consider square footage beyond your home footprint to maximize performance and ensure coverage for outdoor areas.
HOME SHAPE
L or U-shaped homes may need additional satellites to extend WiFi around corners.
WIRED CONNECTIONS
Orbi satellites give your ultra-fast wired connections where you need them.
CONSTRUCTION MATERIALS
Brick and concrete weaken WiFi signals. Add-on satellites will strengthen WiFi coverage.
Products specifications
| Features | |
| Built-in processor | Yes |
| Processor cores | 4 |
| Processor frequency | 2.2 GHz |
| Internal memory | 2000 MB |
| Flash memory | 4000 MB |
| Weight & dimensions | |
| Width | 294 mm |
| Depth | 144.4 mm |
| Height | 130.8 mm |
| Weight | 1.79 kg |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 3 |
| Design | |
| Product type | Mesh satellite |
| Product colour | Black |
| LED indicators | Yes |
| Antenna type | Internal |
| Antennas quantity | 12 |
| Maximum coverage | 200 m² |
| Packaging content | |
| Number of products included | 1 pc(s) |
| AC adapter included | Yes |
| Ethernet cable | Yes |
| Wireless LAN features | |
| Wi-Fi band | Quad-band (2.4 GHz / 5 GHz-1 / 5 GHz-2 / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 11530 Mbit/s |
| WLAN data transfer rate (first band) | 8647 Mbit/s |
| WLAN data transfer rate (second band) | 1147 Mbit/s |
| Security algorithms | WPA3 |
*
*
*
